Description
Basic Info.
Model NO.
| Model NO | SJYZ09-46 | Application | Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane |
| Lift Mechanism | Scissor Lift | Carrying Capacity | Special Weight Level |
| Moves | Self-propelled | Driven Type | Hydraulic |
| Running Mode | Moving | Feature | Explosion-Proof, Insulating |
| Certification | GS, CE, RoHS, ISO 9001 | Model No. | Sjyz0.3-6 |
| Overall Dimensionse | 10300*2200*1200mm | Weight | 18500 Kg |
| Working Height | 6-63m | Transport Package | Wooden Case |
| Trademark | HR | Origin | China |
| HS Code | 8479899990 | Production Capacity | 5000 |
Packaging & Delivery
| Package Size | 210.00cm * 110.00cm * 160.00cm |
| Package Gross Weight | 900.000kg |
Built for durability, this scissor lift requires minimal maintenance and offers reliable performance in diverse environments. Whether for installation, repair, or logistics, it enhances productivity while prioritizing safety.
Ideal for: Construction sites, warehouses, manufacturing plants, and event setups.
Upgrade your operations with our high-performance hydraulic scissor lift – efficiency, safety, and power combined!
Technical Specifications
(Custom configurations available upon request.)
Product model | Table size(mm) | Load capacity(kg) | Net height(kg) | Dimensions(mm) | Weight(kg) | Guardrail(mm) | Power |
SJY0.3-4 | 2100×830 | 300 | 4 | 2200×980×1100 | 800 | 1100 | 1.1KW/220V |
SJY0.3-6 | 2100×830 | 300 | 6 | 2200×950×1200 | 880 | 1100 | 1.1KW/220V |
SJY0.3-7 | 2100×830 | 300 | 7 | 2200×950×1280 | 970 | 1100 | 1.1KW/220V |
SJY0.3-8 | 2100×930 | 300 | 8 | 2200×1060×1380 | 1050 | 1100 | 1.5KW/220V |
SJY0.3-9 | 2100×930 | 300 | 9 | 2200×1060×1500 | 1165 | 1100 | 1.5KW/220V |
SJY0.3-10 | 2100×1230 | 300 | 10 | 2200×1350×1530 | 1360 | 1100 | 2.2KW/380V |
SJY0.3-11 | 2100×1230 | 300 | 11 | 2200×1400×1650 | 1400 | 1100 | 2.2KW/380V |
SJY0.3-12 | 2550×1530 | 300 | 12 | 2720×1670×1750 | 2260 | 1100 | 3KW/380V |
SJY0.3-14 | 2812×1530 | 300 | 14 | 3045×1730×1810 | 2400 | 1100 | 3KW/380V |
SJY0.3-16 | 2812×1600 | 300 | 16 | 3045×1800×2080 | 3500 | 1100 | 3KW/380V |
SJY0.3-18 | 3070×1600 | 300 | 18 | 3250×1800×2080 | 3900 | 1100 | 3KW/380V |
SJY1.0-4 | 2100×1200 | 1000 | 4 | 2200×1350×1180 | 1250 | 1100 | 2.2KW/380V |
SJY1.0-6 | 2100×1200 | 1000 | 6 | 2200×1350×1300 | 1400 | 1100 | 2.2KW/380V |
SJY1.0-8 | 2100×1200 | 1000 | 8 | 2200×1350×1420 | 1585 | 1100 | 2.2KW/380V |
SJY1.0-10 | 2100×1200 | 1000 | 10 | 2200×1350×1530 | 1700 | 1100 | 2.2KW/380V |
SJY1.0-12 | 2550×1530 | 1000 | 12 | 2720×1670×1750 | 2560 | 1100 | 3KW/380V |
SJY1.0-14 | 2812×1530 | 1000 | 14 | 3045×1750×1810 | 2765 | 1100 | 3KW/380V |
SJY1.0-15 | 3070×1600 | 1000 | 15 | 3350×1910×2210 | 5000 | 1100 | 3KW/380V |
SJY1.5-6 | 2100×1530 | 1500 | 6 | 2200×1750×1530 | 1780 | 1100 | 3KW/380V |
Drawings & Dimensions
Detailed CAD drawings and dimensional diagrams are available for download here or upon inquiry. Our engineering team can provide tailored designs to meet specific project requirements.
After Sales Service
Standard Warranty: 12 months or 2,000 operating hours (whichever comes first).
Extended Warranty: Optional coverage up to 36 months.
Global Support: 24/7 technical assistance and spare parts supply.
Training: On-site or remote operation/maintenance training.
Extended Warranty: Optional coverage up to 36 months.
Global Support: 24/7 technical assistance and spare parts supply.
Training: On-site or remote operation/maintenance training.
Company Profile
Hengjinrui (Shandong) Intelligent Manufacturing Co., Ltd.
Hengjinrui (Shandong) Intelligent Manufacturing Co., Ltd. is a leading Chinese manufacturer of construction equipment with over 20 years of expertise. Certified with ISO 9001, CE, and GOST, we export to 50+ countries, offering reliable machinery backed by R&D innovation and strict quality control.
